Thermal Shield Heat Sheath Aluminized Sleeving

Thermal Shield Heat Sheath Aluminized Sleeving is made by fiberglass and aluminum, then use aramid thread or fiberglass thread sewn into a sleeve. It can withstands 1,100 degrees F of continuous radiant heat and 500 degrees F direct heat. Used to protect fuel lines, wiring looms, air intake, intercooler pipes and air conditioner hoses.
  • Description

  • Specifications

Thermal Shield Heat Sheath Aluminized Sleeving made by a high-temperature fabric to a highly-reflective foil, which provides protection from radiant heat for hoses and wires.

The aluminized sleeving reflects over 90% of radiant heat, and is fireproof and oil resistant. Aluminized sleeving solves the problem of heat and abrasions causing failure of lines, hoses & wires.

Designed to slide over wires, cables and hoses, Heat Sheath provides the ultimate protection from extreme heat as well as chemical and oil spills, dirt, grease and road grime.

Pliable for tight bends
Capable of withstanding 2000°F radiant heat
Trim to desired length

NOTE: Each diameter is available up to 100m lengths. Other diameters are also available as a special order. Items with custom cut patterns and/or custom cut lengths of material cannot be returned.

Direct Heat Resistance: 500°F

Radiant Heat Resistance: 2000°F


Datasheet
Material Aluminum, fiberglass
Continuous Temperature 1100 °F
Melt Temperature 2000 °F
Color Silver
Package Plastic Bag
Cutting tools Scissors

Part Number Description
43010 10 mm ID
43012 12 mm ID
43015 15 mm ID
43020 20 mm ID
43025 25 mm ID
43030 30 mm ID
43032 32 mm ID
43035 35 mm ID
43038 38 mm ID
43040 40 mm ID
43045 45 mm ID
43050 50 mm ID
43102 102 mm ID
43110 110 mm ID
43127 127 mm ID
