BSTFLEX fire sleeve make test under R22, R23, and the results of these tests show that the fire sleeves meet HL3.
Test Method | Parameter Unit | Maximum or minimum | HL 1 | HL 2 | HL 3 |
|
T01 (EN ISO 4589-2: OI) |
Oxygen content % | Minimum | 28 | 28 | 32 |
|
T10.03 (EN ISO 5659-2: 25 kWm-2) |
Ds max dimensionless |
Maximum | 600 | 300 | 150 |
|
T11.02
(EN 17084 Method 2 600°C) |
CITNLP dimensionless | Maximum | 1.2 | 0.9 | 0.75 |
|
Our fire sleeve, Oxygen Index 38.2, Smoke Density 72.0, Smoke Toxicity 0.041.
Our fire sleeve also have other certificates, please contact us for more information.
